Application:
It mainly stretch large-sized stretch film into small ones which avoids the split-level film and improves the technical index of product ,such as level and appearance quality etc.
Specification:
| width of parent roll : | 500mm |
| Core specification of parent roll | Φ76mm |
| Max Diameter of parent roll(max)mm | Φ400mm |
| Width of sub-roll | 500mm |
| Core specification of sub-roll | Φ76mm |
| Max Diameter of sub-roll(max)mm | Φ l45mm |
| Max Rewinding speed | 800 m/min |
| Pressure | 6Bar |
| Motor Power | 1.5kw |
| PLC | DELTA |
| Weight (Kg) | 800kg |
| L×W×H | 1400×1100×1650mm |
